Pan: Rimless Trap(s): Universal (S or P Trap) Set outs: S-trap set out 50mm - 75mm as standard. P-trap set out 185mm floor to centre of outlet. Optional S-trap set out 150mm - 170mm (SPB0201). Colour: White Installation: The installation of the toilet suite shall be in accordance with the normal minimum drain line grade requirements in AS/NZS 3500.2. Materials: Vitreous china pan Maintenance and care instructions: Clean with a soft cloth and warm soapy water as necessary - rinse and dry after cleaning. Avoid using abrasive or acid-based cleaning products.
